Please use this identifier to cite or link to this publication: http://hdl.handle.net/10380/3560 |
The Insight Toolkit (ITK) is the premier open source implementation of medical imaging algorithms, with a generic design for image processing filters that allows for many developers to rapidly incorporate these algorithms in to new applications. While ITK filters benefit from a generic, platform independent multithreading capability, the current implementation is difficult to exploit to achieve very high performance. Specifically, ITK relies on a static decomposition of the image into subsets of equal size which can be highly inefficient. Threads that terminate early due to uneven work throughout the image finish early and do not contribute further to the processing of more complex regions, leading to idle computational resources and longer execution times. Performance is also difficult to coordinate across multiple algorithms, as the ITK filter assumes each filter operates independently but the global implementation has an impact across filters.
In this work, we propose a novel, simple to use, high performance multithreading capability for ITK that accelerates the itk::ImageToImageFilter. We utilise a workpile data decomposition strategy, and leave the task of optimal job scheduling on CPU cores to the library called Threading Building Blocks (TBB). We demonstrate the efficacy of multi-threading with TBB in comparison to the itk::Multithreader class, through three simple example image analysis algorithms.
Our implementation provides a new multi-threaded itk::ImageToImageFilter that can be conveniently reused to provide simple and efficient multi-threaded code across applications and algorithm libraries. Our new implementation is distributed as open-source software to the community and is straightforward to adopt.







Authors modernize filter parallelization infrastructure.
Hypothesis:Usage of dynamic domain splitting enables higher efficacy of parallel filters with unbalanced workload.
Evidence:The authors tested their method on 3 different examples, to showcase the extent of the improvement.
Open Science:The authors provide source code, input images and bash scripts to generate quantitative results.
Reproducibility:The source code was quick and easy to compile (I already had a compiled version of TBB). The provided readme was sufficient.
Use of Open Source Software:The authors clearly explained that this class provides speedup only for unevenly balanced workloads (variable processing time for different pixels).
They mentioned thread recycling between executions in the classic parallel model, but did not explain whether TBB keeps the thread pool alive between different filter executions.
They neglected to mention that TBB is an inconveniently big dependency, and that unbalanced workloads are less common than (moslty) balanced ones.
Open source Contributions:The main contribution is templated class implemented in a pair of headers, which makes it very usable. The test "examples" are non-trivial applications themselves.
Code Quality :I only took a look at the main class, not the examples. The code was easy to read and surprisingly short.
Quality of the data :I am not that familiar with DWI, so I cannot judge the quality of the supplied test data, but the data is in a convenient format.
